The “Revowrap” composite systems are engineered to operate in working temperatures from -50°C to 232°C and bares minimal pressure limitations.
Our composite systems can be applied by hand lamination or by infusion methods and may be applied to live piping REVOWRAP SYSTEMS -50°C to 232°C with no pressure limitations! systems without shutting down for the repair.
Revowrap may be applied to any pipe size, most substrates and almost any piping configuration including tanks, vessels, flanges, and other compromised structural assets.
The Spitze HP clamp is engineered and manufactured in accordance with ASME VIII Div 1 for the temporary repair of live high-pressure leaks without having to shut down or isolate the system. The low-profile standoff height of the clamp is intended for a composite overwrap using any of the Revowrap systems for long terms repairs. The Spitze HP clamp is resistant to the harsh chemical environment
prevalent in the oil, gas and petrochemical industries.
The Spitze HP clamp is engineered to operate in working temperatures from -60°C to 380°C and has a pressure rating of up to 200 Bar with a maximum application pressure of 150Bar.
Please refer to the maximum and minimum service temperatures of the various Spitze bungs as illustrated in the SPITZE BUNG column below.
The installation of the Spitze HP clamp is non-invasive and may be applied to live piping systems without shutting down for the repair on hole sizes up to 25mm Diameter. Spitze HP clamp may be applied to piping sizes up to 56”, and may be installed on most substrates and is suitable for Subsea application.
